Description
Features
Compact and lightweight
Allow the printer to easily fit into even the smaller spaces and shelves in a home.
Auto Power ON/OFF
Auto Power ON detects a print command and will automatically switch the printer on with a USB connection and automatically switches off after a specific timing.
Low Cost Cartridges
Affordable ink cartridges for high quality printing.
| Print Head/Consumables | |
| Number of Nozzles | Total 1,280 nozzles |
| Ink Cartridges (Type/Colours) | PG-745S (Pigment Ink/Black), CL-746S (Dye-based Ink/Colour) [Optional: PG-745, CL-746 / PG-745XL, CL-746XL] |
| Maximum Print Resolution | 4,800 (Horizontal)*1Â x 600 (Vertical) dpi |
| Print Speed*2Â (Approx.)
Click here for summary report |
|
| Document (ESAT/Simplex) | 8 / 4 ipm (Mono/Colour) |
| Print Width | Up to 203.2 mm (8″) |
| Recommended Printing Area | Top margin: 31.6 mm Bottom margin: 29.2 mm |
Scan*3
| Scanner Type | Flatbed (Platen) |
| Scanner Technology | Contact Image Sensor (CIS) |
| Optical Resolution*4 | 600 x 1,200 dpi |
| Scanning Bit Depth (Input/Output) | |
| Greyscale | 16 bit / 8 bit |
| Colour | 48 bit / 24 bit (RGB each 16 bit / 8 bit) |
| Maximum Document Size | |
| Flatbed | A4, LTR (216 x 297 mm) |
Copy
Paper Handling
| Print Margin | |
| Bordered Printing | LTR/LGL: Top margin: 3 mm, Bottom margin: 16.7 mm Left margin: 6.4 mm, Right margin: 6.3 mm Others: |
| Supported Media | |
| Rear Tray | Plain Paper (64 – 105 g/m²) High Resolution Paper (HR-101N) Photo Paper Plus Glossy II (PP-201, PP-208) Envelope |
| Paper Size | |
| Rear Tray | A4, A5, B5, LTR, LGL, Envelope (COM10, DL), 4 x 6″, 5 x 7″
[Custom Size]
Width: 101.6 – 215.9 mm Length: 152.4 – 676 mm *F4 is possible via custom settings. |
| Maximum Capacity | |
| Rear Tray | Plain Paper, 64 g/m² (A4, A5, B5, LTR, ): 60 Photo Paper Plus Glossy II (PP-201, PP-208, 4 x 6″): 20 Envelope (COM10, DL): 5 |
| Paper Weight | |
| Rear Tray | Plain Paper: 64 – 105 g/m² Canon Paper: Approx. 275 g/m² (Max.) (Photo Paper Plus Glossy II, PP-201) |
System Requirements
| OS System Compatibility*6 | Windows 8 / 7 / Windows Vista / Windows XP, macOS X 10.7.5 or later |
General Specifications
| Interface | USB 2.0 |
| Operating Environment*7 | |
| Temperature | 5 – 35°C |
| Humidity | 10 – 90% RH (no dew condensation) |
| Recommended Environment*8 | |
| Temperature | 15 – 30°C |
| Humidity | 10 – 80% RH (no dew condensation) |
| Storage Environment | |
| Temperature | 0 – 40°C |
| Humidity | 5 – 95% RH (no dew condensation) |
| Power Requirements | AC 100 – 240 V, 50/60 Hz |
| Power Consumption (Approx.) | |
| OFF | 0.4 W |
| Standby | 1 W |
| Operation*9 | 9 W |
| Dimensions (W x D x H) | |
| Factory Configuration | 426 x 306 x 145 mm |
| Weight | 3.5 kg |
Page Yield*10
| Plain Paper Click here for more information |
A4 Colour Documents*11: PG-745S / CL-746S: 100 pages Optional: |
